FSFP16MW-BL

165W Rigid Solar Panel

FSFP16MW-BL

165W Rigid Solar Panel

High efficiency monocrystalline solar panel with built-in high bypass diodes for optimal performance under high temperature and low light environments.

Learn More

MSRP $699.95

Share
  • Rigid Solar Panel

    Description

    Furrion Rigid Solar Panels are constructed of high efficiency monocrystalline solar cells to optimize sunlight efficiency in all conditions, and provide long term output stability and reliability. Built with high transmittance, low iron tempered glass with enhanced stiffness and impact resistance for durability. Built-in bypass diodes further ensure high power output in shaded, or otherwise low light environments.Z-mounting brackets (C-FSFP16MW-A02) and Rooftop Box (FSEB30JWL-BL) need to be puchased separately.

    Key Features

    165W Rated Power

    Monocrystalline Cells

    Bypass High Transmittance diodes

    Ultra clear Low iron tempered glass

    Short Circuit and Surge Protection

    Higher than average efficiency

    Furrion PV connectors ready






    • Max Power
    • Max Power Voltage (Vmp)
    • Max Power Current (Imp)
    • Open Circuit Voltage (Voc)
    • Short Circuit Current
    • Cell Efficiency
    • Maximum System Voltage
    • Series Fuse Rating
    • Max Power
      165W
    • Max Power Voltage (Vmp)
      18.72V
    • Max Power Current (Imp)
      8.82A
    • Open Circuit Voltage (Voc)
      23.12V
    • Short Circuit Current
      9.49A
    • Cell Efficiency
      20%
    • Maximum System Voltage
      600V
    • Series Fuse Rating
      15A
  • Specifications



    Download Specifications

    User Manual



    Download User Manual
