FACR14SA-BL-AM

14.5K Rooftop unit for Furrion Chill Air Conditioner System

FACR14SA-BL-AM

14.5K Rooftop unit for Furrion Chill Air Conditioner System

Aerodynamically designed and powerful air conditioner for your RV, this unit has been engineered with dual fans to increase cooling efficiency and lower operating noise.

24 months limited warranty


Available in:
  • Black
  • White
MSRP $899.95

Share
  • Mobile living with superior comfort

    Description

    Furrion’s aerodynamically designed, mid profile air conditioner has been engineered with leading features such as dual-fan technology, isolated plastic base, and lightweight insulated heat exchanger housing. Stable temperature controls, improved running efficiency, and noise reduction are all benefits of its innovative design. With up to 25% more efficiency (EER) over leading competitive single-fan models, and comfort control settings such as “sleep mode,” the Furrion CHILL meets the demand for any living condition

    Key Features

    - Advanced cooling performance

    - Fit for manual and electronic air distribution box

    - Dual fans run more efficiently and reduce operating noise

    - Cleanable and replaceable air filter

    - Available in stylish black and white options

    • Capacity
    • EER
    • Set Temperature Range
    • Outdoor Sound Pressure Level
    • IP class
    • Refrigerant
    • Volts/Frequency/Phase
    • Power (Cooling)
    • Amps (Cooling)
    • Capacity
      3450W
    • EER
      2.13
    • Set Temperature Range
      60°F to 86°F/16°C to 30°C
    • Outdoor Sound Pressure Level
      80dB
    • IP class
      IP24
    • Refrigerant
      R410A
    • Volts/Frequency/Phase
      115V/60Hz/1Ph
    • Power (Cooling)
      1620Watts
    • Amps (Cooling)
      14.6
  • Specifications



    Download Specifications

    User Manual



    Download User Manual
  • How to install and setup a Furrion Chill® dip switch

  • There could be several reasons for this to happen to your AC unit. One of the first things you should do is check for any air leakages between the supply and return air sides. Other common problems include the duct divider not being properly sealed, the room temperature sensor not being placed appropriately, or your air filter being too dirty to function properly. If you need help with your AC unit because you think it is not functioning properly, please don’t hesitate to get in touch with a specialist.

    One possible solution for this is to try running the indoor fan on the AC at all times - even during heating. This is to ensure an even spread of temperature and more accurate thermostat readings.

    If your rooftop RV air conditioner keeps switching itself off, this could be because the temperature outside is too low, triggering the thermostat-controlled switch. Alternatively, all the air nozzles might be closed causing an issue. If neither of these seems to be the cause of your problem, please do not hesitate to get in touch with us.

    If your rooftop RV AC unit is not functioning as well as you like, there may be several root causes. Before anything, you could double-check that your rooftop air conditioner is set to the cooling mode. Secondly, check that you cannot set the temperature on the air conditioner any lower. Apart from this, here are some possible problems and solutions. -
    Your air intake grills may be blocked or obstructed, preventing the RV AC unit from functioning as intended. To solve this, remove any leaves or other dirt from the ventilation grills on the top of the rooftop air conditioner.
    - Your blower may also be defective. If you believe this to be the case, please contact an authorized service agent or Furrion directly.
    - The evaporator is another potential cause of this problem, as it may have been damaged. If this is the case, you will need to contact an authorized service agent or Furrion.
    - Lastly, the condenser fan is another component that, if damaged, will cause issues like this. Like other damaged parts, please contact a service agent or Furrion.

    If water is entering your camper as you use the AC unit, there may be a blockage in the water drainage openings for condensation to escape. You can try to clean up these drainage openings first but, if there is no improvement, you may have broken seals. Should this be the case, you will need to contact an authorized service agent or Furrion.

    There are several possible causes for this:
    - First, your supply voltage might not be connected properly. Try checking the power supply before suspecting other issues.
    - Alternatively, the voltage supplied to your rooftop 12V DC air conditioner might not be sufficient to power it. If you suspect this to be the case, please contact an authorized service agent or Furrion for a solution.
    - Lastly, the fuse might have blown. You can check the electrical fuse of the power supply for this.

    Show more
    Show less

WARNING: Cancer - www.P65Warnings.ca.gov

Customer Reviews

Based on 6 reviews
100%
(6)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
W
Ward J. Masur
easy install

Easy installation. Cooled camper down in a matter of minutes on a 92 degree day.

C
Clint Lail
Very easy install. Runs great!

Very easy install . Replacement of my old camper unit from a Coleman. Instructions could have been more clear. But after a little research it was a breeze!

S
Sandra Romkey
AC for RV

Works GREAT!

B
BPM
Good unit. About an hour to install.

Went in easy and cools great. Tabs that hold the shroud on we're snapped during shipping. Got ahold of the manufacturer and they sent a new one.

W
Waffles00
Fantastic customer service.

I ordered 2 of these units, the first set is still to this day lost in shipping, but that is on the freight company.
I contacted the seller and they immediately sent out 2 new units via Fedex and they showed up a couple days later.
Like most peoples complaints, the cover was not usable due to damage, however the main units were still in perfect operating condition. I once again contacted the seller and they Sent 2 new covers.
Once installed, I'm super impressed, they are quiet, draw less amps, and move way more air the the 2008 model dometic unit i had. These units will directly replace a dometic Ac and be plug and play, even the mounting hardware is the same.
Using the dometic control board with analog thermostat it only has 2 fan speeds. I may re wire the inside fan motor to run on high and low, instead of high and medium.

E
Edward Montalvo
Great Cooling

Came with a preinstalled gasket. The ac isn’t super quiet but not as loud as some of the others on the market. Cools pretty well. Unfortunately Bad reviews are only due to shipping and not the actual product. The styling of this unit is very modern compared to the outdated and more expensive models. I used a single unit in a 32ft travel trailer. The box is pretty heavy (80lbs) so you’ll need to figure out a way to hoist it into the roof of the RV.
